Wall & Ceiling Panels
Engineered to create controlled, airtight, and contamination-free environments for sensitive manufacturing and processing areas. Designed with precision jointing and high-performance insulation, these panels support strict cleanliness standards while maintaining stable internal temperatures and energy efficiency.
Colour Shades
Clean Room Wall & Ceiling Panels are supplied with a standard colour-coated finish selected to meet functional zoning, architectural coordination, and environmental exposure requirements. The pre-coated metal facings are factory-finished to ensure uniform colour consistency, corrosion resistance, and long-term surface stability under industrial and coastal operating conditions.
Select Color:
Product Specifications
| CHARACTERISTICS | SPECIFICATIONS |
|---|---|
| Panel thickness available | 50mm, 80mm, 100mm, |
| Panel width available | 1000 mm, 1160 mm, 1150 mm, 1200 mm |
| Panel length available | 1000 -12000mm |
| Nominal Density | 40±2 Kg/m³ |
| Thermal conductivity@25°mean temperature | 0.023-0.03W/m²k |
| Thermal Transmittance ( U-Value) | 0.6-0.12kcal/m²∙h∙°C |
| Thermal Resistance (R-Value) | 1.4-8.3kcal/m²∙h∙°C |
| Compressive Strength@10% deformation | 0.11-0.21N/mm² |
| Tensile Strength | 1.1-2.5kg/cm² |
| HOT DIMENSIONAL STABILITY OF LENGTH, WIDTH, THICKNESS(max) @ 85±2°C/100±2°C FOR 24Hrs – MAX | ±2% |
| COLD DIMENSIONAL STABILITY @ – 25±2°C FOR 24 Hrs – MAX | ±2% |
| Free from | CFC, HFC & HCFC free |
Key Performance Attributes
Outlining Essential performance parameters influencing insulation, strength, and installation efficiency.
Dust-Free Enclosure
Sealed panel surfaces and tight joints help prevent dust accumulation and airborne contamination.
Airtight Jointing System
Specially designed joinery minimizes air leakage, supporting controlled and sterile environments.
Thermal Stability
Insulated panel construction helps maintain consistent internal temperatures.
Energy-Efficient Performance
Reduced air leakage and effective insulation help lower energy consumption during operation.
Related Products
Available Panel Joints
Mount’s panel joint configurations ensure precise alignment, secure interlocking, and effective load transfer, enhancing structural continuity, air and moisture tightness, and installation efficiency while maintaining long-term durability .
Roof Joint
Single Tongue & Groove Joint
Double Tongue & Groove Joint
Hidden Tongue & Groove
Camlock Joint
M Section
Applications
Wide-ranging applications for Clean Room Wall & Ceiling Panels
Pharmaceutical Manufacturing Facilities
Used to maintain sterile conditions in drug formulation and production areas.
Biotechnology & Life Sciences Laboratories
Supports controlled environments for research, testing, and biological processes.
Medical Devices & Equipment Manufacturing
Ensures cleanliness during assembly and handling of sensitive medical components.
Food & Beverage Processing Units
Applied in hygiene-critical areas requiring contamination control.
Electronics & Microelectronics Manufacturing
Protects sensitive components from dust during assembly and testing.
Semiconductor Manufacturing Facilities
Supports precision processes requiring strict particulate control.
Cosmetics & Personal Care Manufacturing
Maintains clean conditions for formulation and packaging operations.
Aerospace & Aviation Component Assembly
Used in controlled zones for precision manufacturing and inspection.
Frequently asked Question
They are insulated sandwich panels designed to create airtight, dust-controlled environments for clean room applications.
Sealed surfaces and precision jointing reduce dust traps and limit air leakage.
Yes, they are designed for use in wall, ceiling, and partition systems.
Yes, the insulated core helps maintain stable internal temperatures.
Through specially designed joinery systems that ensure tight panel connections.
Yes, smooth surfaces allow easy cleaning and routine maintenance.
Yes, they are widely used in pharmaceutical and healthcare manufacturing environments.
Yes, airtight construction and insulation help reduce HVAC energy loads.
Yes, they are commonly used where dust and contamination control is critical.
Cleanliness class, airtightness requirements, thermal performance, and applicable industry standards.
